應用領域：
11-37KW
型號 | 篩網 層數 | 篩孔尺寸 （mm） | 進料尺寸 （mm） | 處理能力 （m3/h） | 電動機型號 | 電機功率 （kw） | 篩面規格 （mm） | 總重量 | 外形尺寸 長x寬x高 （mm） |
2YA1237 | 2 | 3-50 | 300 | 10-80 | Y160M-4 | 11 | 1200x3700 | 3.6 | 4600x1900x1200 |
3YA1237 | 3 | 3-50 | 300 | 10-80 | Y160M-4 | 11 | 1200x3700 | 3.9 | 4730x1900x1650 |
4YA1237 | 4 | 3-50 | 300 | 10-80 | Y160M-4 | 11 | 1200x3700 | 4.5 | 4900x1900x2150 |
2YA1548 | 2 | 3-100 | 300 | 22-260 | Y160L-4 | 15 | 1500x4800 | 4.6 | 5700x2260x1200 |
3YA1548 | 3 | 3-100 | 300 | 22-260 | Y160L-4 | 15 | 1500x4800 | 5.1 | 5900x2260x1650 |
4YA1548 | 4 | 3-100 | 300 | 22-260 | Y160L-4 | 15 | 1500x4800 | 5.6 | 6050x2260x2100 |
2YA1848 | 2 | 3-100 | 300 | 32-380 | Y180M-4 | 18.5 | 1800x4800 | 5.35 | 5720x2560x1200 |
3YA1848 | 3 | 3-100 | 300 | 32-380 | Y180M-4 | 18.5 | 1800x4800 | 6 | 5900x2560x1650 |
4YA1848 | 4 | 3-100 | 300 | 32-380 | Y180M-4 | 18.5 | 1800x4800 | 6.65 | 6050x2560x2100 |
2YA1860 | 2 | 3-100 | 300 | 65-586 | Y180M-4 | 22 | 1800x6000 | 6 | 6920x2560x1200 |
3YA1860 | 3 | 3-100 | 300 | 65-586 | Y180M-4 | 22 | 1800x6000 | 6.6 | 7100x2560x1650 |
4YA1860 | 4 | 3-100 | 300 | 65-586 | Y180M-4 | 22 | 1800x6000 | 7.2 | 7250x2560x2100 |
2YA2160 | 2 | 3-100 | 300 | 81-720 | Y200L-4 | 30 | 2100x6000 | 10.1 | 7020x3090x1320 |
3YA2160 | 3 | 3-100 | 300 | 81-720 | Y200L-4 | 30 | 2100x6000 | 11.3 | 7160x3090x1780 |
4YA2160 | 4 | 3-100 | 300 | 81-720 | Y200L-4 | 37 | 2100x6000 | 12.5 | 7320x3090x2230 |
2YA2460 | 2 | 3-150 | 300 | 90-810 | Y225S-4 | 37 | 2400x6000 | 11.6 | 7020x3390x1320 |
3YA2460 | 3 | 3-150 | 300 | 90-810 | Y225S-4 | 37 | 2400x6000 | 12.8 | 7160x3390x1780 |
4YA2460 | 4 | 3-150 | 300 | 90-810 | Y225S-4 | 37 | 2400x6000 | 14 | 7320x3390x2230 |
